STOPLIK STYLE 7400 / 7499
(Covered Under Design Patent Registration No. 178193)

Structure : PTFE / Graphite yarn reinforced with Graphited fibre.
Equipment : Centrifugal pumps, thermic fluid pumps, agitator reactor vessels and glass lined reactors etc.
Application : Recommended for slurry application with very acidic or alkaline pH along with Stoplik Style 8000E or In-Situ Mold Stoplik Style 77 HS, can also be used for thermic fluid pumps intermittently. Stoplik Style 7499 is recommended for harsh slurry application.

STOPLIK STYLE 99
(Covered Under Design Patent Registration No. 178195)

Structure : PTFE / Graphite yarn reinforced with Synthetic fibre.
Equipment : High speed centrifugal and reciprocating pumps, cooling tower pumps, ash slurry pumps, water ring vacuum pumps, condensate extraction pumps, boiler feed pumps, mixers, agitator reactor vessels, rotary vacuum driers, valves, refiner and pulp transfer pumps in pulp and paper industries etc.
Application : Recommended for acids, alkalies, slurry, sea-water.

STOPLIK STYLE 707
(Covered Under Design Patent Registration No. 178194)

Structure : PTFE / Graphite yarn reinforced with Aramid fibre.
Equipment : High pressure reciprocating pumps, carbamate pumps, phosphate dozing pumps, high pressure agitator reactor vessels, valves etc.
Application : Recommended for chemicals, dyes and intermediates, pesticide and fertilizer industries, thermal power stations etc.

STOPLIK STYLE 5588
(Covered Under Design Patent Registration No. 174483)

Structure : PTFE / Graphite yarn reinforced with Graphited and recuperating Synthetic fibre.
Equipment : Mixers, agitator reaction vessels etc.
Application : Recommended for specific applications.

STOPLIK STYLE 3400
(Covered Under Design Patent Registration No. 178191)

Structure : PTFE yarn reinforced with Graphited fibre.
Equipment : Centrifugal pumps, agitator reactors, mixers, glass lined reactors, rotary vacuum driers etc.
Application : Recommended for organic solvents and volatile chemicals including benzene, toluene, acetone, xylene, ethanol, methanol, ammonia, mono chloro benzene, carbon tetrachloride, chloroform etc.

STOPLIK STYLE 33
(Covered Under Design Patent Registration No. 178192)

Structure : PTFE yarn reinforced with Synthetic fibre.
Equipment : Reciprocating and centrifugal pumps, water ring vacuum pumps, mixers, agitator reactor vessels, autoclaves, rotary vacuum driers etc.
Application : Recommended for handling chemicals where Graphite contamination is not desirable.

STOPLIK STYLE 303
(Covered Under Design Patent Registration No. 178194)

Structure : PTFE yarn reinforced with Kevlar fibre.
Equipment : High pressure reciprocating pumps, high pressure agitator reactor vessels, carbamate pumps, phosphate dozing pumps and valves etc.
Application : Recommended for chemicals, dyes and intermediates, pesticides and fertilizer industries, thermal power stations etc.

STOPLIK STYLE 4488
(Covered Under Design Patent Registration No. 174483)

Structure : PTFE yarn reinforced with recuperating Synthetic fibre.
Equipment : Agitator reactor vessels, mixers etc.
Application : Recommended for specific applications.

STOPLIK CUSTOM BUILT* HOLLOW CORE PATENTED REINFORCED YARN GLAND PACKING

Structure : Reinforced PTFE and PTFE / Graphite yarn braided over square hollow rubber core.
Equipment : Agitator nutch filter, agitator reactor vessels, mixers, clinker grinder, etc. In chemical, drugs, dyes, pigments, pesticides, allied process industries and power stations etc.
Application : Stoplik Hollow Core packing is specifically designed to reduce packing wear and shaft / sleeve wear in slow rotating equipments with excess shaft run-out. Stoplik Hollow Core packing resists gland follower load and excess run-out or whip in shaft. Gland adjustments and repacking are greatly reduced. Months of in-plant testing have proved that Stoplik's reinforced yarn packing with square hollow core will out last conventional packing in application associated with excessive shaft deflection on large shaft. Stoplik Hollow Core packing are offered as per the suitability of the application and service.

*THE PACKING IS OFFERED IN SIZE OF 1/2" AND ABOVE.
Above image shows a worn-out sleeve due to use of conventional packin

Advantages of Patented Reinforced Yarn Hollow Core Gland Packing:

• 100% custom built product.
• Rubber in the core provides recuperation, more than 95%.
• Excellent gland pressure transfer, more than 95%.
• Finger tightening of gland follower sealing, more than 98%.
• Packing length increases due to Hollow rubber core.
• Seals even in run out condition of shaft without damaging it.
• Resists gland follower load and excessive run out or whip in the shaft.
